Pet Pellet 80kg/H Floating Fish Feed Machine Single Screw Mia
Product Details:
| Place of Origin: | Hebei, China |
| Brand Name: | BEST |
| Certification: | ISO9001, ISO14001, OHSAS18001, CE, SONCAP, PVOC |
| Model Number: | BEST |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 1500-3800/SET |
| Packaging Details: | Field installation, commissioning and training |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 set per unit |
|
Detail Information |
|||
| Produce Name: | Feed Processing System | Weight: | 220 Kg To 3800 Kg |
|---|---|---|---|
| Capacity: | 80kg/h | Warranty: | 3 Years |
| Application: | Pet, Fish | Voltage: | 380 V |
| Lifespan: | 5 Years | Advantage: | Easy Operation High Efficiency |
| Type: | Feed Pellet Machine, Single Screw Extruder Machine | Oil Seal: | Made In Germany |
| High Light: | 80kg/h floating fish feed machine,single screw floating fish feed machine,80kg/h fish feed pellet machine |
||
Product Description
Feed Processing System Pet Pellet Feed Fish Floating Machine Mia
1. Feed processing system introduction
Mainly suitable for a variety of aquatic products, pet and other pellet feed mature molding processing (such as: floating, sinking fish ingredients, frog feed, pellet suckling pig feed, etc.)
2. Fish floating machine specification
| Model | Capacity (t/h) | Main Motor (kw) | Feed motor (kw) | Diameter | Size( mm) | Weight (kg) |
| DGP40-C | 0.03-0.04 | 4.0 | 0.4 | Φ40 | 1400*1030*1200 | 220 |
| DGP50-C | 0.06-0.08 | 11 | 0.4 | Φ50 | 1470*1100*1250 | 320 |
| DGP60-C | 0.10-0.15 | 15 | 0.4 | φ60 | 1470*1120*1250 | 350 |
| DGP70-B | 0.18-0.2 | 18.5 | 0.4 | φ70 | 1650*1400*1300 | 580 |
| DGP80-B | 0.2-0.3 | 22 | 0.6 | φ80 | 1800*1450*1300 | 695 |
| DGP90-B | 0.3-0.4 | 37 | 0.6 | φ90 | 2100*1450*1350 | 950 |
| DGP120-B | 0.5-0.6 | 55 | 1.1 | φ120 | 2400*1950*1600 | 1700 |
| DGP135-B | 0.7-0.8 | 75 | 1.1 | φ133 | 2550*2050*1650 | 1900 |
| DGP160-B | 1.0-1.2 | 90 | 1.5 | φ155 | 3100*2650*1800 | 3200 |
| DGP200-B | 1.8-2.0 | 132 | 2.2 | φ195 | 3100*2850*1900 | 3800 |
3. Working principle
1. During the extrusion operation, the material is input from one end of the machine cavity opening, and is transported to the whole machine cavity by the screw, however The rear extrusion parts are divided into several areas, each area with a ring (pressure ring) For the flow rate and pressure control. The transport effect of the screw pushes the material through the pressure ring and the inside of the chamber The ring gap between, the mechanical energy generated by the rotation of the screw due to the friction between the material and the components of the extruder Wipe and internal friction of the material are converted into heat energy
2. In most cases, these materials rich in starch and protein are simultaneously cooked into a sticky dough or Glutinous dough. In the process of converting the material into this state, a large number of physical and chemical materials occur Learning changes, mainly is the result of starch in materials and protein changes
3. When the material is squeezed through the mold hole at the end of the machine cavity, the dough-like material is processed into a certain shape. Due to the huge propulsion of the screw in the cavity, a huge pressure forms in the materials when these materials From the moment of extrusion from the mold hole, it vaporizes a large amount of water in the material, which is greatly reduced The moisture content in the material
